Specifications

SIZE PLY RATING LOAD RANGE Load Speed Index Tread Depth (32nd) Max load Single (lbs) Max Pressure Single (psi) Max load Dual (lbs) Max Pressure Dual (psi) Rim Width (IN) OD (in) SW (in) Revs / Mile WEIGHT (LBs)
Tread construction
10R22.5 14PR G 141/139L 18 5675 115 5355 115 7.5 40.1 10.3 503 99.8 1S+4S
11R22.5* 14PR G 144/142L 18 6175 105 5840 105 8.25 41.5 11 486 111.4 1S+4S
11R22.5* 16PR H 146/143L 18 6610 120 6005 120 8.25 41.5 11 486 111.4 1S+4S
11R24.5* 14PR G 146/143L 18 6610 105 6005 105 8.25 43.5 11 464 119.5 1S+4S
11R24.5* 16PR H 149/146L 18 7160 120 6610 120 8.25 43.5 11 464 119.5 1S+4S
215/75R17.5 16PR H 135/133L 15 4805 125 4540 125 6 30.2 8.3 668 58.1 1S+4S
235/75R17.5 18PR J 143/141J 15 6005 125 5675 125 6.75 31.4 9.2 643 66 1S+4S
245/70R17.5 18PR J 136/134M 17 4940 125 4675 125 7.5 30.9 10 652 68.7 1S+4S
245/70R17.5 18PR J 143/141J 17 6005 125 5675 125 7.5 30.9 10 652 68.7 1S+4S
225/70R19.5 12PR F 125/123L 15 3640 95 3415 95 6.75 32 8.9 632 65.2 1S+3S
225/70R19.5 14PR G 128/126L 15 3970 110 3750 110 6.75 32 8.9 632 65.2 1S+3S
245/70R19.5 14PR G 133/131M 16 4540 110 4300 110 7.5 33.1 10 611 73.4 1S+4S
245/70R19.5 16PR H 136/134M 16 4940 120 4675 120 7.5 33.1 10 611 73.4 1S+4S
265/70R19.5 14PR G 137/134M 18 5070 110 4675 110 7.5 34.5 10.3 591 82.2 1S+4S
295/75R22.5* 14PR G 144/141L 18 6175 110 5675 110 9 39.9 11.7 505 106.9 1S+4S
295/75R22.5* 16PR H 146/143L 18 6610 120 6005 120 9 39.9 11.7 505 106.9 1S+4S
255/70R22.5 16PR H 140/137M 17 5510 120 5070 120 7.5 36.6 11 551 84.7 1S+4S
275/70R22.5 18PR J 148/145L 18 6940 130 6390 130 8.25 37.7 10.9 535 107.1 1S+4S
285/75R24.5* 14PR G 144/141L 18 6175 110 5675 110 8.25 41.3 11.2 505 112.1 1S+4S
285/75R24.5* 16PR H 147/144L 18 6780 120 6175 120 8.25 41.3 11.2 505 112.1 1S+4S
