Specifications

SIZE PLY RATING LOAD RANGE Load Speed Index Tread Depth (32nd) Max load Single (lbs) Max Pressure Single (psi) Max load Dual (lbs) Max Pressure Dual (psi) Rim Width (IN) OD (in) SW (in) Revs / Mile WEIGHT (LBs)
Tread construction
11R22.5* 14PR G 144/142L 26 6175 105 5840 105 8.25 41.5 11 486 119.1 1S+4S
11R22.5* 16PR H 146/143L 26 6610 120 6005 120 8.25 41.5 11 486 119.1 1S+4S
11R24.5* 14PR G 146/143L 26 6610 105 6005 105 8.25 43.5 11 464 127.1 1S+4S
11R24.5* 16PR H 149/146L 26 7160 120 6610 120 8.25 43.5 11 464 127.1 1S+4S
225/70R19.5 14PR G 128/126L 19 3970 110 3750 110 6.75 32 8.9 632 65.4 1S+3S
245/70R19.5 14PR G 133/131L 19 4540 110 4300 110 7.5 33.1 9.8 611 72.8 1S+4S
295/75R22.5 14PR G 144/141L 26 6175 110 5675 110 9 40.2 11.7 505 115.4 1S+4S
295/75R22.5 16PR H 146/143L 26 6610 120 6005 120 9 40.2 11.7 505 115.4 1S+4S
285/75R24.5 14PR G 144/141L 26 6175 110 5675 110 8.25 41.6 11.2 505 119.5 1S+4S
285/75R24.5 16PR H 144/141L 26 6780 120 6175 120 8.25 41.6 11.2 505 119.5 1S+4S
