Specifications

SIZE PLY RATING LOAD RANGE Load Speed Index Tread Depth (32nd) Max load Single (lbs) Max Pressure Single (psi) Max load Dual (lbs) Max Pressure Dual (psi) Rim Width (IN) OD (in) SW (in) Revs / Mile WEIGHT (LBs)
Tread construction
11R22.5 14PR G 144/142L 27 6175 105 5840 105 8.25 41.5 11 486 121.7 1S+4S
11R22.5 16PR H 146/143L 27 6610 120 6005 120 8.25 41.5 11 486 121.7 1S+4S
11R24.5 14PR G 146/143L 27 6610 105 6005 105 8.25 43.5 11 464 129.7 1S+4S
11R24.5 16PR H 149/146L 27 7160 120 6610 120 8.25 43.5 11 464 129.7 1S+4S
295/75R22.5 14PR G 144/141L 27 6175 110 5675 110 9 40 11.7 505 115.7 1S+4S
295/75R22.5 16PR H 146/143L 27 6610 120 6005 120 9 40 11.7 505 115.7 1S+4S
