DH106ET Features
Extended Lifespan: Closed shoulder design and deep tread depth of 30/32nds promotes even wear and increases mileage over the life of the tire
Stone Drilling Protection: Stone ejector grooves effectively prevent stone drilling—preserving the casing and ensuring maximum retreadability
Exceptional Traction & Mileage: Specialized tread blocks add stability, grip and overall durability
Better Starts & Stops: Optimized siping enhances starts, acceleration, and braking
Additional Features
- EPA SmartWay® verified
|
Tire Size
|
Ply Rating
|
Load Range
|
LI/SR Single/Dual
|
Tread Depth 32nd
|
Max Load Single lbs
|
Max Pressure Single psi
|
Max Load Dual lbs
|
Max Pressure Dual lbs
|
Approved Rim Width
|
O.D. in
|
S.W. in
|
Revs/Mile
|
Weight lbs
|
Tread Construction
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 11R22.5 | 14PR | G | 144/142L | 30 | 6175 | 105 | 5840 | 105 | 7.50,8.25 | 42 | 11 | 493 | 133 | 1S + 4S |
| 11R22.5 | 16PR | H | 146/143L | 30 | 6610 | 120 | 6005 | 120 | 7.50,8.25 | 42 | 11 | 493 | 133 | 1S + 4S |
| 11R24.5 | 14PR | G | 146/143L | 30 | 6610 | 105 | 6005 | 105 | 7.50,8.25 | 44 | 11 | 471 | 142 | 1S + 4S |
| 11R24.5 | 16PR | H | 149/146L | 30 | 7160 | 120 | 6610 | 120 | 7.50,8.25 | 44 | 11 | 471 | 142 | 1S + 4S |
| 295/75R22.5 | 14PR | G | 144/141L | 30 | 6175 | 110 | 5675 | 110 | 8.25,9.00 | 40 | 12 | 508 | 130 | 1S + 4S |
| 295/75R22.5 | 16PR | H | 146/143L | 30 | 6610 | 120 | 6005 | 120 | 8.25,9.00 | 40 | 12 | 508 | 130 | 1S + 4S |
| 285/75R24.5 | 14PR | G | 144/141L | 30 | 6175 | 110 | 5675 | 110 | 7.50,8.25,9.00 | 41 | 11 | 494 | 134 | 1S + 4S |
| 285/75R24.5 | 16PR | H | 147/144L | 30 | 6780 | 120 | 6175 | 120 | 7.50,8.25,9.00 | 41 | 11 | 494 | 134 | 1S + 4S |
All specifications subject to change.
